ROCKPANEL® board material is used, mostly in ventilated constructions, for facade cladding, roof detailing, soffits and fascias. The product is manufactured from the sustainable rock, basalt. ROCKPANEL® is a very robust and flexible board material which fits perfectly with modern trends such as organic shapes and sustainability, with a strong emphasis on cost efficiency and short installation times. www.Rockpanel.com EPD Number: BREG EN EPD 000145 Date of issue: 19 December 2016 Expiry Date: 18 December 2021 BF1331ECOP Rev 0.3 Page 3 of 9 © BRE Global Ltd 2016 Technical Information Property Value Unit Thickness 9.0 ± 0.5 mm Length, max 3050 mm Width, max 1250 mm Density, nominal 1250 ± 100 kg/m³ length and width f₀₅ Bending strength (BS EN 310 / EN 1058) greater than or equal to N/mm² 25.5 greater than or equal to Modulus of elas city N/mm² 4740 Thermal conduc vity 0.55 W/(m.K) Fire classi ca on, on aluminium subframe A2-s1, d0 n/a Product Contents Material/Chemical Input % Stone wool 90 - 92 Binder 7-9 Cured coa ng 0 - 2.5 Manufacturing Process The sustainable ROCKPANEL® board material is - like all ROCKWOOL products - produced from the natural source basalt rock. This is the volcanic rock from which all ROCKWOOL products derive their unique properties. The basalt is melted and spun into fibres. From these fibres the high density board is pressed in a state of the art press line. The board is finished with a waterborne coating system which has a high durability. Products such as the Woods, Metallics and Chameleon are finished with an extra ProtectPlus coating which creates a self-cleaning surface with an even higher weathering resistance. EPD Number: BREG EN EPD 000145 Date of issue: 19 December 2016 Expiry Date: 18 December 2021 BF1331ECOP Rev 0.3 Page 4 of 9 © BRE Global Ltd 2016 The process flow diagram is shown below: Construction Installation ROCKPANEL® FS-Xtra boards are fastened to aluminium sub-frames. Fastening to aluminium sub-frame is carried out with co
